Cast Sheets (A Cast)
A Cast is a cast acrylic sheet that has become synonymous with clarity, colors and choice. The versatility of the material and wise range of colors, surfaces and finishes enable designers to quickly realize their creative ideas.
A-Cast cast acrylic is a product that has become synonymous with clarity, colors and choice. The fabrication behavior of the material and wide range of colors, surfaces and finishes enable designers and fabricators to quickly realize their creative ideas.
Acrylic Cast Sheets (A Cast)
Specification
PRODUCT FEATURES
Size : 1220 X 1830 (4×6) MM
Available – 2mm to 50mm
Size : 1220 X 2440 (4×8) MM
Available – 2mm to 50mm
Size : 2030 X 3050 MM
Available – 3mm to 30mm
Product Range:
Clear, Opal White, Opaque White, Frosted, Neutrals, Fluorescent, Silk Matt, Edge lit, Glass look, Black & White and Colours
| Item | Test Method and Conditions | Unit | Test Result |
| General | |||
| Specific gravity | ASTM D-792 : 2000 | – | 1.19 |
| Relative density | ISO 1183 | – | 1.09 |
| Water absorption rate (24 hrs) | ASTM D-570 | % | 0.2 |
| Vicat softening point (Full) | ASTM D-1525 : 2006 | ◦C | Min110 |
| Mechanical | |||
| Tensile strength | ASTM D-638 : 2003 | mPa | 71 |
| Elongation at Break | % | 4 | |
| Flexural strength | ASTM D-790 : 2003 | mPa | 98 |
| Flexural modulus | 2800 | ||
| Izod impact strength(notched) | ASTM D-256 : 2000 | J/m | 20 |
| Rockwell Hardness | ASTM D-785 : 2003 | M scale | 104 |
| Optical | |||
| Total light transmittance | ASTM D-1003 | % | 93 |
| Haze | 0.5 | ||
| Refractive index (ηD²⁰) | ASTM D-542 : 2006 | – | 1.49 |
| Thermal | |||
| Heat deflection | ASTM D-648 : 2006 | ◦C | 105 |
| Flammability | ASTM D-635 : 2003 | mm/min | 30 |
| Linear expansion coefficient | ASTM E-831 : 2006 | mm/mm/°C | 5.5 x 10¯⁵ |
We’ll update you with the PDF.
